Shown: reference 5990/1R-001 · Photo: Patek Philippe
Patek Philippe

Nautilus 5990/1R-001 Reference 5990/1R-001

Overview

A 40.5 mm rose gold case with a blue dial defines the Patek Philippe Nautilus 5990/1R-001. The movement is the self-winding Patek Philippe calibre CH 28-520 C FUS, with a power reserve of 45 to 55 hours. Water resistance is 30 metres. The model has one reference, 5990/1R-001.

Patek Philippe launched the Nautilus in 1976 as a sports watch in steel. About the Patek Philippe Nautilus

Case diameter
40.5 mm
12.53 mm thick
Movement
Calibre CH 28-520 C FUS
Flyback, Chronograph
Water resistance
30 m
Power reserve
45 to 55 h

Specifications

Specifications from Patek Philippe. Last checked . Sources

Case

Diameter
40.5 mm
Thickness
12.53 mm
Material
Rose gold
Crystal
Sapphire
Case back
Open
Water resistance
30 m

Dial

Colour
Sunburst blue, horizontally embossed, rose gold applied baton-style hour markers with white luminescent coating. Local time hand: rose gold rounded baton-style with white luminescent coating. Home time hand: rose gold skeletonized rounded baton-style.

Movement

Type
Automatic
Power reserve
45 to 55 h
Jewels
34
Frequency
28,800 vph (4 Hz)
Certification
Patek philippe seal

Bracelet or strap

Bracelet or strap
Rose gold
Clasp
Rose gold fold-over clasp

Not yet recorded: lug width, lug-to-lug, shape, indexes, hands, years.

Sources

  • Patek Philippe: case, water resistance, dial, movement, bracelet. View sources

Missing values are shown as not yet recorded, never estimated. How we source our data

MovementPatek Philippe calibre CH 28-520 C FUSSpecifications and every watch that uses it

Nautilus 5990/1R-001 questions

What size is the Patek Philippe Nautilus 5990/1R-001?

The Patek Philippe Nautilus 5990/1R-001 has a 40.5 mm case.

What movement does the Patek Philippe Nautilus 5990/1R-001 use?

It uses the Patek Philippe calibre CH 28-520 C FUS.

What is the Patek Philippe Nautilus 5990/1R-001 case made of?

The case is rose gold.

Is the Patek Philippe Nautilus 5990/1R-001 water resistant?

It is rated to 30 m.

About the Patek Philippe Nautilus

Patek Philippe launched the Nautilus in 1976 as a sports watch in steel. It was designed by Gérald Genta, and its case is inspired by a ship's porthole, with a rounded octagonal bezel and a horizontally embossed dial. The original reference was the steel 3700/1A, nicknamed the Jumbo. The collection now includes time-only models alongside complications such as Travel Time, chronograph, moon phase, annual and perpetual calendar, in steel, rose gold and white gold. Patek Philippe marks the Nautilus's 50th anniversary in 2026.

Sources: Nautilus collection (Patek Philippe), The Complete Guide to the Patek Philippe Nautilus (Sotheby's), Fratello's Top 5 Patek Philippe Nautilus References (Fratello)
